Product Overview

BLY-01 180° Peel Strength Tester is a high‑precision electronic peel testing instrument developed by Sumspring. It is strictly designed and manufactured in accordance with GB/T 2792 (Test method for 180° peel strength of pressure‑sensitive adhesive tapes), BB/T 0093‑2022 (Peel test standard for liner‑free labels), GB/T 30775 (Peel testing standard for protective films), and YBB pharmaceutical packaging standards. The instrument is specifically designed for accurate 180° peel strength testing of various adhesive products, including pressure‑sensitive tapes, self‑adhesive labels, protective films, medical patches, and composite packaging materials. It is a core quality control instrument for the adhesive, packaging, pharmaceutical, and electronics industries.

Key Features & Advantages

Full Compliance with National Standards – Data Traceability Guaranteed

Strictly complies with GB/T 2792, BB/T 0093, GB/T 30775, YBB, and other national, industry, and pharmacopoeia standards. Test speed, sample pressing, force acquisition, and data algorithms are fully standardized. Test results can be directly used for certification, system audits, and third‑party laboratory submissions.

High‑Precision Sensor – Captures Micro‑Force Changes with Precision

Equipped with an imported force sensor featuring 0.001 N ultra‑high resolution and Class 1 test accuracy. It accurately captures minute peel force fluctuations, effectively avoiding issues such as uneven peeling, initial peak interference, and constant‑speed deviation. Data stability and repeatability far exceed conventional testing equipment.

Stepless Speed Control – Adaptable to Various Materials

Supports stepless speed adjustment from 1 to 500 mm/min. Test speed can be freely set according to tape viscosity, label material, or film thickness – suitable for low‑tack protective films, medium‑tack tapes, and high‑tack adhesives. One instrument covers the full range of adhesive products.

Fully Automatic Data Processing – No Manual Calculation Required

The entire test process is fully automated, with real‑time force‑displacement curve plotting. The system automatically calculates maximum, minimum, and average peel strength values. Data storage, query, export, and report printing are fully supported – eliminating manual reading, recording, and calculation errors.

Standard Pressure Roller Included – Compliant Sample Preparation

Comes standard with a 2000 g ± 50 g pressure roller in full compliance with national standards, ensuring consistent sample pressing pressure, no bubbles, and no false adhesion – eliminating data deviations caused by non‑standard sample preparation and ensuring excellent test repeatability.

Robust Construction – Suitable for Long‑Term High‑Frequency Use

The machine features a reinforced metal frame with electrostatic spray coating for rust and corrosion protection. The transmission system is precision‑engineered for smooth, stable operation with no sticking. Long‑term continuous testing shows no drift or deviation, with low failure rates – ideal for factory high‑throughput QC and laboratory high‑frequency calibration.

User‑Friendly Interface – Quick to Learn and Operate

Intelligent menu‑style interface with clearly defined functional zones. Parameters can be set with one click and tests started with a single button – no professional testing experience required. Simple training enables operators to complete the full test process independently, significantly reducing QC labor costs.

Applications

Packaging & Printing Industry – 180° peel strength testing of self‑adhesive labels, liner‑free labels, carton sealing tapes, and packaging adhesives

Pharmaceutical Packaging – Compliance testing of medical patches, medical tapes, pharmaceutical composite films, and adhesive excipients

Electronics & Auxiliary Materials – Peel force testing of protective films, anti‑static tapes, insulating films, and double‑sided tapes

Adhesive & New Materials – Formulation R&D, performance benchmarking, and quality calibration of pressure‑sensitive adhesives, hot‑melt adhesives, and flexible bonding materials

Building & Protective Films – Peel strength testing of PE protective films, architectural films, and decorative films – compliant with GB/T 30775

Testing Institutions & Research Institutes – Product certification testing, material research, teaching experiments, and standard compliance testing
