Product Overview

ZPY-60U Electronic Axis Deviation Tester is designed for measuring the circular runout of ampoules and the vertical axis deviation of vials. Manufactured in accordance with national standards including YBB00332002-2015 "Low Borosilicate Glass Ampoules" and other NMPA standards, it is an indispensable instrument for pharmaceutical enterprises, drug control laboratories, and the food industry.

Testing Principle

The bottle body is fixed on the rotating platform. A high-precision dial gauge reads the displacement at the bottle mouth during one full rotation. The vertical axis deviation is calculated from the difference between the maximum and minimum readings.

High-Concentricity Rotating Platform:

Built on a precision three-jaw self-centering chuck, ensuring that the bottle axis is highly aligned with the rotation center, significantly improving measurement accuracy.

Versatile Multi-Functional Bracket:

Features a multi-dimensional adjustable design, enabling quick adaptation to different bottle heights and diameters. The device offers strong versatility and convenient operation.

Key Features & Advantages

Dual-function design – can test both vertical axis deviation and circular runout, with easy user switchover

Motorized probe lift – automatically adjusts measuring position for convenient operation

Large color LCD display – shows test results, including individual measurements and statistical values

Large touch screen control – clear, intuitive, and easy to operate

High-speed processor chip – significantly improves operating speed

High-precision micro-sensor – captures measurement errors in real time, no battery replacement required

Built-in micro printer – prints complete test information including instrument serial number, sample batch number, operator, test results, and test date/time

Unique 4-level user hierarchical permission management – ensures data integrity and standardization

Customizable permission control – flexible definition of access rights at each level, strictly limiting who can perform specific operations

Comprehensive password protection – prevents unauthorized access and ensures data traceability

Advanced data recording and storage technology – ensures every test record remains complete, secure, and tamper-proof

ISP online upgrade capability – provides customized service

GMP-compliant data storage format – automatic processing and statistical analysis of test data

Optional Sumspring Link-DMS software system – allows raw data to be backed up on a computer as an unalterable database and exported as PDF files

Applications

Designed for suitable for glass bottle manufacturers, optical instrument manufacturers, and laboratories for measuring stress values in optical glass, glass products, and other optical materials.
